Optical
Light source: OSRAM Lok-it! 1400/PS Brilliant
Expected average lifetime: 750 hours
Beam angle: Zoom range 5˚ - 55˚
Focus: Variable range, from 5m to infinity
Prism: 3-facet prism, CW/CCW rotation, variable speed
Frost: On/Off
Ballast: Electronic
Animation effect: Aluminium animation wheel, used alone or in combination with gobos, rotating in both directions at variable speed

Photometric
Total Output (Lumen): 33600 lm
Color temperature: 5600K
CRI: ≥92

Gobo
Rotating gobo: 5 interchangeable gobos + open, indexing, CW/CCW rotation, variable speed
Static gobo wheel:  7 gobos + open, CW/CCW rotation, variable speed
Gobo outside diameter: 33 mm
Max. Image diameter: 27 mm
Max. Thickness: 0.5 mm(Metal)/5.0 mm(Glass)
Glass/Metal gobo: Glass/Metal

Color
Color wheel: 7 colors + open, split color, CW/CCW rotation, variable speed
CMY / CTO: CMY + CTO for linear infinity color mixing

Electrical
Power input, nominal: AC 200-240V 50/60Hz
Max. Power consumption: 1790W
Power supply unit: Auto-ranging electronic SMPS
Main fuse: 250V/15A

Control/programming
Control channels (DMX): 37/34/54
Protocol: DMX-512, RDM, and ArtNet optional
Display: Graphic LCD backlit
16-bit control: Dimmer, CMY colors, CTO, focus, zoom, pan/tilt, gobo indexing & rotation, rotating gobo wheel positioning

Physical/Installation
Weight: 42 kg(92.6 lbs.)
IP rating: IP20
Material: Aluminum, steel, plastic
Mounting points: Four quarter-turn locking points + attachment points for safety wire
Minimum distance to combustible materials: 0.5 mtr(1.64 ft.)
Minimum distance to illuminated surfaces: 5 mtr(16.4 ft.)

Dynamic effects
Pan/Tilt movement: 540˚/ 270˚
Iris: 5-100% high speed, with built-in macros
Strobe: 1-20Hz, synchronized, pulse effects
Dimmer: 0-100%, 16-bit, mechanical dimming
Zoom: Motorized
Built-in macros: Color, Iris
Framing: Rotating module +/- 45˚, 4 shutter blades, full crossover of each blade, angle of each blade +/- 45˚

Thermal
Operating range: 14˚F - 113˚F(-10˚C - 45˚C)
Startup range: 5˚F - 113˚F(-15˚C - 45˚C)
Storage range: -40˚F - 140˚F(-40˚C - 60˚C)
Cooling: Active fan
Humidity: ≤ 85%

Connections
AC power: Neutrik powerCon
DMX data input/output: Chassis 3-pin & 5-pin Neutrik XLR (in/out)

Certification and Safety
EMC: EN 55103-1:2009, EN 55103-2:2009, EN 61000-3-2:2006+A2:2009, EN 61000-3-3:2013
Safety: EN 60598-2-17:1989/A2:1991

Included items
User manual
4.92 ft. (1.5m) cable with Neutrik PowerCon
2 x G-clamp, for Ø42-52mm, Max. 200 kg
