Optical
Light source: Single CW (5400K - 5800K) 300W LED light source
Expected average lifetime: 50000 hours
Beam angle: Zoom range 13° - 49°
Photometric
Total Output (Lumen): 14720 lm narrow/17450 lm wide
Color temperature: 5400K - 5800K
CRI: ≥96
Electrical
Power input, nominal: AC 100-240V 50/60Hz
Max. Power consumption: 310W
Power supply unit: Auto-ranging electronic SMPS
Main fuse: 250V/5A
Control and programming
Control channels (DMX): 4/6
Protocol: DMX-512
Display: Graphic LCD backlit
16-bit control: Dimmer
Physical / Installation
Weight: 11.6 kg(25.6 lbs.)
IP rating: IP20
Material: Aluminum, steel, plastic
Mounting points: 12mm holes for G-Clamp
Minimum distance to combustible materials: 0.5 mtr(1.64 ft.)
Minimum distance to illuminated surfaces: 1 mtr(3.3 ft.)
Dynamic effects
Pan/Tilt movement: Manually adjustable
Strobe: 1-25Hz, synchronized, pulse effects
Dimmer: 0-100%, 16-bit, electronic linear dimming
Zoom: Manually adjustable
Thermal
Operating range: 14˚F - 113˚F(-10˚C - 45˚C)
Startup range: -13˚F - 113˚F(-25˚C - 45˚C)
Storage range: -40˚F - 140˚F(-40˚C - 60˚C)
Cooling: Active fan
Humidity: ≤85%
Connections
AC power: Neutrik powerCon
DMX data input/output: Chassis 5-pin Neutrik XLR (in/out)
Certification and Safety
EMC: EN 55103-1:2009, EN 55103-2:2009, EN 61000-3-2:2006+A2:2009, EN 61000-3-3:2013
Safety: EN 60598-2-17:1989/A2:1991
