Optical
Light source: 12W (RGBW 4-in-1) 54 LEDs
Expected average lifetime: 50000 hours
Beam angle: 19° (27° and 43° optional)

Photometric
Total Output (Lumen): 6900 lumens
Color temperature: 3200K - 7200K linear regulation
Mixing distance: > 0.3 mtr (1.0 ft.)

Electrical
Power input, nominal: AC 200-240V - 50/60Hz
Max. Power consumption: 170W
Power supply unit: Auto-ranging electronic SMPS

Control / Programing
DMX Protocol modes: 2
Control channels (DMX): 15/8
Protocol: DMX-512
Display: 4 x 8 segment display
16-bit control: Dimmer, R,G,B,W colors

Physical / Installation
Weight: 7.5 kg (16.5 lbs.)
IP rating: IP65
Material: Aluminium
Mounting points: One quarter-turn locking point + attachment points for safety wire
Minimum distance to combustible materials: 0.5 mtr (1.64ft.)
Minimum distance to illuminated surfaces: 1 mtr (3.3ft.)

Dynamic effects
Pan movement: Manually adjustable
Tilt movement: Manually adjustable
Strobe: 1-25Hz, synchronized, pulse effects
Dimmer: 0-100%, 16-bit, electronic linear dimming
Built-in macros: Color

Thermal
Operating range: 14˚F - 113˚F (-10˚C - +45˚C)
Startup range: 5˚F - 113˚F (-15˚C - +45˚C)
Storage range: -40˚F - 140˚F (-40˚C - +60˚C)
Cooling: Passive
Humidity: ≤ 98%

Connections
AC power: 1.64 ft. (0.5m) cable with water proof plugs (in/out)
DMX data input/output: 2 x 1.64 ft. (0.5m) cable with 5-pin Neutrik IP65 XLR plugs (in/out)

Certification and Safety
EMC: EN 55103-1:2009, EN 55103-2:2009, EN 61000-3-2:2006+A2:2009, EN 61000-3-3:2013, GB/T 17743-2007, GB 17625.1-2012
Safety: EN 60598-2-17:1989/A2:1991, GB 7000.1-2015, GB 7000.217-2008

Included items
User manual
4.92 ft. (1.5m) cable with water proof plug

Order information
8301030601 - 6 x L1254P , in 6 unit flight case
8301030602 - 1 x L1254P , in single cardboard box
8301030603 - 1 x L1254P, customized

Accessories
1503030204 - Flight case, 6 unit for L1254P series
1503080018 - G-clamp, for Ø42-52mm, Max. 200 kg
Notes
Sleep mode
